Front of SHJP-C1300 Inspection Machine

This machine adopts three asynchronous servo motor control, German rex inverter adjustment, hydraulic or pneumatic automatic feeding, reduce the feeding time, more simple and easy operation, save time and effort, and improve production efficiency. This machine using Siemens PLC computer automatic control, 10 inch touch screen operation, with automatic meter, intelligent length shutdown, emergency shutdown, automatic tension, etc., roll the feeding platform type, feed level, convenient pneumatic pressure, roll the unaxis type roll, professional and efficient detection of material defects, can be equipped with trimming function at the same time

Classification:

Product inspection machine

Key words:

Front of SHJP-C1300 Inspection Machine

E-Mail：

wenjinbao@sh-slittingmachine.com

Tel / Wechat / WhatsApp：

+86 15157748066

Product Message
Contact Us

Product Description

Items 1300 Parameters
Testing materials Optical film，Paper，Soft packaging industry，Printing materials
Raw material Width 300mm（Wheel Face Width 1350mm）
Maximum Unwinding Diameter Φ800mm
Maximum Take-up Diameter Φ800mm
Detection width 20-1300mm
The ness of rewinding end surface ±0.2mm
Inside Diameter of Take-up Die 3inch（76.2mm）
Mechanical Running Speed 0-400M/min（Design Speed，Due To Material Characteristics）
Power  Supply 380V 50HZ 3PHASE
Total Machine Power 18KW
Air Pressure Source 3KW（Prepared By Customer）
Machine Size Length2900mm×Width2100mm×Height2100mm
Machine Weight 3200KG（Conjoined Machine）
Detection Mode Detecting System
Tension Control Method Auto-control
The previous image
The following text The width of this model can be customized 600-2200mm, the maximum diameter of winding is 800mm, and the maximum diameter of winding is 800mm

User value

Qualification Honor

The company adheres to the design concept of "green, energy saving, low carbon", and has always been committed to providing customers with reliable and qualified products. We organize production in strict accordance with technical standards, and our products have passed various export certifications and testing reports such as ISO9001 quality system, and won the honor of high-tech enterprises, specialized and special new enterprises.
